| PartZenbakia | PA050XS7 |
| Marka | E Ink |
| Tamaina | 5.0 |
| Aplikazio | CNS |
| Ebazpena | 320×234 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 350:1 |
| Koloreak | Full color |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | PVI |
| panel eredua | PA050XS7 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 320(RGB)×234 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 102.72×74.53 mm |
| eskema | 126.4×92.3×13.2 mm |
| azalera | |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 350:1 (Typ.) |
| bistaratzeko koloreak | Full color |
| erantzun denbora | 15/30 (Typ.)(Tr/Td) |
| ikuspegi angelua | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | TFT Specific Analog RGB, 30 pins |
| sarrerako tentsioa | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| aplikazio | CNS |
| PA050DS2T1 | E Ink | 5.0 | 320×234 |
| PA050DS4 | E Ink | 5.0 | 320×234 |
| PA050DS7 | E Ink | 5.0 | 320×234 |
| PA050DS7N1 | E Ink | 5.0 | 320×234 |
| PA050DT2 | E Ink | 5.0 | 320×234 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PA050XSG | E Ink | 5.0 | 320×234 |
| PA050XSH | E Ink | 5.0 | 320×234 |
| PA050XU4 | E Ink | 5.0 | 320×234 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| C043GW01 V0 | AUO | 4.3 | 400×234 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| FG0700K5DSSWBG01 | Data Image | 7.0 | 800×480 |
| LA061WQ1-TD05 | LG Display | 6.1 | 480×272 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| TX31D16VM2BAA | KOE | 12.2 | 1024×310 |
