| PartZenbakia | LQ065Y5DZ01 |
| Marka | SHARP |
| Tamaina | 6.5 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 675 |
| CR | 1700:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ065Y5DZ01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 6.5 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | ASV, Normally Black, Transmissive |
| eremu aktiboa | 141.6×84.96 mm |
| eskema | 161.8×100.6×17.5 mm |
| azalera | |
| distira | 675 cd/m² (Typ.) |
| kontraste-erlazioa | 1700:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 15/5 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | Parallel RGB (1 ch, 4-bit), 68 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | CNS |
