| PartZenbakia | P070ACB-DB1 |
| Marka | Innolux |
| Tamaina | 7.0 |
| Aplikazio | PAD |
| Ebazpena | 600×1024 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | CHIMEI INNOLUX |
| panel eredua | P070ACB-DB1 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 600(RGB)×1024 , WSVGA |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 89.28×152.37 mm |
| eskema | 95×163.27×4.15 mm |
| azalera | Hard coating (7H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S3PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 39 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| CLAA070ND36CW | CPT | 7.0 | 1024×600 |
| CLAA070NP01HXG | CPT | 7.0 | 1024×600 |
| ED070NA-01N | Innolux | 7.0 | 1024×600 |
| G070Y2-L01 | Innolux | 7.0 | 800×480 |
| HSD070I651-F20 | HannStar | 7.0 | 480×234 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| VVX07H005A10 | Panasonic | 7.0 | 800×1280 |
| B079XAN02.0 CELL | AUO | 7.9 | 768×1024 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| LD070WX3-SL01 | LG Display | 7.0 | 800×1280 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| LTL070NL01-801 | Samsung | 7.0 | 1024×600 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
