| PartZenbakia | LSL080AL02-002 |
| Marka | Samsung |
| Tamaina | 8.0 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | No B/L |
| Interfazea | MIPI |
| panel marka | SAMSUNG |
| panel eredua | LSL080AL02-002 |
| panel mota | a-Si TFT-LCD , CELL |
| panelaren tamaina | 8.0 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | PLS, Normally Black, Transmissive |
| eremu aktiboa | 107.64×172.224 mm |
| eskema | 112.64×181.824×0.69 mm |
| azalera | Glare (Haze 0%), Hard coating |
| beiraren sakonera | 0.20+0.20 mm |
| transmisibitatea | 6.6% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | MIPI (4 data lanes), 34 pins |
| sarrerako tentsioa | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| aplikazio | PAD |
