| PartZenbakia | ED070NA-01N |
| Marka | Innolux |
| Tamaina | 7.0 |
| Aplikazio | MP4 |
| Ebazpena | 1024×600 |
| Konposizioa | Assembly |
| Distira | 210 |
| CR | 700:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | INNOLUX |
| panel eredua | ED070NA-01N |
| panel mota | a-Si TFT-LCD , Assembly |
| panelaren tamaina | 7.0 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| eremu aktiboa | 153.6×90 mm |
| eskema | 184.9×121.3×4.8 mm |
| azalera | Hard coating (7H) |
| distira | 210 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| ikuspegi angelua | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 40 pins |
| sarrerako tentsioa | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | MP4 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN93 V.2 | Innolux | 7.0 | 800×480 |
| C070VAN01.1 | AUO | 7.0 | 800×480 |
| C070VVN03.0 | AUO | 7.0 | 800×480 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| ED070NA-01N | Innolux | 7.0 | 1024×600 |
| LB070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD03 | LG Display | 7.0 | 800×480 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
| TX18D37VM0ARA | KOE | 7.0 | 800×480 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| CLAA070NC0BCT | CPT | 7.0 | 1024×600 |
| CLAA070ND22CW | CPT | 7.0 | 1024×600 |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| HJ070NA-13D | Innolux | 7.0 | 1024×600 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LMS430HF11-003 | Samsung | 4.3 | 480×272 |
| LTP700WV-F01 | Samsung | 7.0 | 800×480 |
| Q070LRE-L81 | Innolux | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
