| PartZenbakia | LTP700WV-F02 |
| Marka | Samsung |
| Tamaina | 7.0 |
| Aplikazio | DPF |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 300:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | SAMSUNG |
| panel eredua | LTP700WV-F02 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800×480(RGB) , WVGA |
| bistaratzeko modua | TN, Normally White, TMR |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 165×104×5.7 mm |
| azalera | |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 300 : 1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193158% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| rohs: | |
| aplikazio | DPF |
