| PartZenbakia | LQ070Y3DG02 |
| Marka | SHARP |
| Tamaina | 7.0 |
| Aplikazio | DPF |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 280 |
| CR | 450:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ070Y3DG02 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800×480(RGB) , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 164.9×104×5.3 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 280 cd/m² (Typ.) |
| kontraste-erlazioa | 450:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193148% |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 8S3PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit), 51 pins |
| sarrerako tentsioa | 1.8/2.85V (Typ.)(VDDIO/VCI) |
| aplikazio | DPF |
