| PartZenbakia | Q07021-701 |
| Marka | Innolux |
| Tamaina | 7.0 |
| Aplikazio | DPF |
| Ebazpena | 800×600 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 400:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | CHIMEI INNOLUX |
| panel eredua | Q07021-701 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×600 , SVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 141.6×106.2 mm |
| eskema | 154×119.2×5.25 mm |
| azalera | Antiglare |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193145% |
| erantzun denbora | 5/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S6PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 60 pins |
| sarrerako tentsioa | 3.3/12.0V (Typ.)(VCC/VDD) |
| aplikazio | DPF |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| LTL070AL01-L01 | Samsung | 7.0 | 1280×800 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| PW070DS1T6 | E Ink | 7.0 | 480×234 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
| A104SN01 V0 | AUO | 10.4 | 800×600 |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| CLAA070MA21BW | CPT | 7.0 | 800×600 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| LTA104S1-L01 | Samsung | 10.4 | 800×600 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
