| PartZenbakia | AT056TN52 V.3 |
| Marka | Innolux |
| Tamaina | 5.6 |
| Aplikazio | DPF |
| Ebazpena | 640×480 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 500:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | INNOLUX |
| panel eredua | AT056TN52 V.3 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.6 inch |
| ebazpena | 640(RGB)×480 , VGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 112.896×84.672 mm |
| eskema | 126.5×100×6 mm |
| azalera | Antiglare |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 10/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S5PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit), 50 pins |
| sarrerako tentsioa | 3.3/5.0/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikazio | DPF |
