| PartZenbakia | H546DLK01.0 |
| Marka | AUO |
| Tamaina | 5.5 |
| Aplikazio | Mobile Phone |
| Ebazpena | 1080×1920 |
| Konposizioa | AM-OLED , OLED |
| Distira | |
| CR | 10000:1 |
| Koloreak | 16.7M |
| Atzeko argia | self |
| Interfazea | MIPI |
| panel marka | AUO |
| panelaren tamaina | 5.5" |
| ebazpena | 1080(RGB)×1920, FHD, 403PPI |
| bistaratzeko eremua | 68.04(W)×120.96(H) mm |
| eskema tamaina | 70.84(W)×128.01(H) ×0.92(D) mm |
| distira | 350 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥1600) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 100% NTSC |
| maiztasuna | 100Hz |
| gidariaren ic | COG Built-in RM69071 |
| panelaren pisua | - |
| seinale interfazea | MIPI (4 data lanes) |
| sarrerako tentsioa | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | H546DLK01.0 |
| panel mota | AM-OLED , OLED |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Hard coating (3H) |
| kontraste-erlazioa | 10000:1 (Min.) (TM) |
| bistaratzeko modua | - |
| erantzun denbora | - |
| lanpara mota | self |
| pantaila taktila | Embeded Touch |
| aplikazio | Mobile Phone |
