| PartZenbakia | C070VW04 V2 |
| Marka | AUO |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | AUO |
| panel eredua | C070VW04 V2 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | AMVA, Normally Black, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 165.55×106.01×7.48 mm |
| azalera | Antiglare, Antireflection |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193155% |
| erantzun denbora | 10/25 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S3PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 50 pins |
| sarrerako tentsioa | 3.3/12.5/15.0/-9.0V (Typ.)(VDD/AVDD/VGHVGL) |
| aplikazio | CNS |
| C070VAN01.1 | AUO | 7.0 | 800×480 |
| C070VAN01.3 | AUO | 7.0 | 800×480 |
| C070VTN01.0 | AUO | 7.0 | 800×480 |
| C070VTN02.0 | AUO | 7.0 | 800×480 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AT056TN52 V.4 | Innolux | 5.6 | 640×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| ND068-101A1 | 6.8 | 1280×480 | |
| P070BAG-CM1 | Innolux | 7.0 | 1024×600 |
| PA079DS1T3 | E Ink | 7.9 | 480×234 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
