| PartZenbakia | AV128HDM-NW0 |
| Marka | BOE |
| Tamaina | 12.8 |
| Aplikazio | CNS |
| Ebazpena | 1280×720 |
| Konposizioa | LCM |
| Distira | 500 |
| CR | 900:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE |
| panel eredua | AV128HDM-NW0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 12.8 inch |
| ebazpena | 1280(RGB)×720 , WXGA |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| eremu aktiboa | 283.2×159.3 mm |
| eskema | 300.8×179.5×8 mm |
| azalera | |
| distira | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193172% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4S10PWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 50 pins |
| sarrerako tentsioa | 3.3/11.5/22/-9V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikazio | CNS |
