| PartZenbakia | LQ070Y5DG36 |
| Marka | SHARP |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 485 |
| CR | 150:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ070Y5DG36 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800×480(RGB) , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 156.4×82.08 mm |
| eskema | 165.2×92.4×11.06 mm |
| azalera | |
| distira | 485 cd/m² (Typ.) |
| kontraste-erlazioa | 150:1 (Min.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 20/30 (Typ.)(Tr/Td) |
| ikuspegi angelua | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S4PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | CNS |
