| PartZenbakia | B101XTN01.1 |
| Marka | AUO |
| Tamaina | 10.1 |
| Aplikazio | NBPC |
| Ebazpena | 1366×768 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | B101XTN01.1 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1366(RGB)×768 , WXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 222.52×125.11 mm |
| eskema | 243×146.5×3.6 mm |
| forma estiloa | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| azalera | Antiglare, Hard coating (3H) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193145% |
| erantzun denbora | 8 (Typ.)(Tr+Td) |
| ikuspegi angelua | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NBPC |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| N101LGE-L11 | Innolux | 10.1 | 1024×600 |
| B104SN01 V0 | AUO | 10.4 | 800×600 |
| HSD121PHW1-A01 | HannStar | 12.1 | 1366×768 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LP141WP1-TLA3 | LG Display | 14.1 | 1440×900 |
| LP141WX1-TLA1 | LG Display | 14.1 | 1280×800 |
| LTD111EWAS | TOSHIBA | 11.1 | 1366×768 |
| LTN156AT17-D02 | Samsung | 15.6 | 1366×768 |
| N133HSG-WJ1 | Innolux | 13.3 | 1920×1080 |
| N154I4-L03 | Innolux | 15.4 | 1280×800 |
| NL8060BC26-15 | NLT | 10.4 | 800×600 |
