| PartZenbakia | ED090NA-01D |
| Marka | Innolux |
| Tamaina | 9.0 |
| Aplikazio | PAD |
| Ebazpena | 1280×800 |
| Konposizioa | Assembly |
| Distira | 200 |
| CR | 700:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | CHIMEI INNOLUX |
| panel eredua | ED090NA-01D |
| panel mota | a-Si TFT-LCD , Assembly |
| panelaren tamaina | 9.0 inch |
| ebazpena | 1280(RGB)×800 , WXGA |
| eremu aktiboa | 193.92×121.2 mm |
| eskema | 235.12×156.4×7.84 mm |
| azalera | Hard coating (7H) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| ikuspegi angelua | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 51 pins |
| sarrerako tentsioa | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | PAD |
