| PartZenbakia | B101EAN01.6 |
| Marka | AUO |
| Tamaina | 10.1 |
| Aplikazio | PAD |
| Ebazpena | 1280×800 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | B101EAN01.6 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1280(RGB)×800 , WXGA |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| eremu aktiboa | 216.96×135.6 mm |
| eskema | 227.72×147.8×4.6 mm |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193150% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S4PWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 8-bit), 36 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| LC104S1-A1 | LG Display | 10.4 | 800×600 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| LTL070NL01-801 | Samsung | 7.0 | 1024×600 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
