| PartZenbakia | AM-1280800P4TZQW-T11H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial |
| Ebazpena | 1280×800 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 6S4P |
| Interfazea | |
| panel marka | AMPIRE |
| panelaren tamaina | 7.0" |
| ebazpena | 1280(RGB)×800, WXGA, 217PPI |
| bistaratzeko eremua | 149.76(W)×93.6(H) mm |
| eskema tamaina | 162.3(W)×107.9(H) ×11.8(D) mm |
| distira | 850 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 50% NTSC |
| maiztasuna | 60Hz |
| pisua | - |
| panel eredua | AM-1280800P4TZQW-T11H |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 152.76(W)×96.6(H) mm |
| azalera | - |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| lanpara mota | 6S4P WLED , 50K hours , With LED Driver |
| pantaila taktila | PCAP |
| aplikazio | Industrial |
