| PartZenbakia | AA070MC11 |
| Marka | Mitsubishi |
| Tamaina | 7.0 |
| Aplikazio | IA |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 1300 |
| CR | 1000:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | Mitsubishi |
| panel eredua | AA070MC11 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 169.8×109.7×9.4 mm |
| azalera | Clear, Hard coating (3H) |
| distira | 1300 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| erantzun denbora | 12/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 stringsWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| AA070MC01 | Mitsubishi | 7.0 | 800×480 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| HSD070IDW1-A21 | HannStar | 7.0 | 800×480 |
| LD070WX4-SM01 | LG Display | 7.0 | 800×1280 |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| NL8048AC19-13 | NLT | 7.0 | 800×480 |
| AA150XN04 | Mitsubishi | 15.0 | 1024×768 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| EL640.480-AG1 ET LP | PLANAR | 8.1 | 640×480 |
| LJ640U35 | SHARP | 8.9 | 640×400 |
| M190EG01 V0 | AUO | 19.0 | 1280×1024 |
| M190EG01 V2 | AUO | 19.0 | 1280×1024 |
| NL6448BC26-15 | NLT | 8.4 | 640×480 |
| TCG121SVLQAPNN-AN20 | Kyocera | 12.1 | 800×600 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
