| PartZenbakia | AM-1024600K5TMQW-T00H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial |
| Ebazpena | 1024×600 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 700:1 |
| Koloreak | 16.7M |
| Atzeko argia | 5S3P |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-1024600K5TMQW-T00H |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 169PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 153.6 × 90 (H×V) |
| eskema (mm) | 165.5 × 103 × 11.02 (H×V×D) |
| luminantzia | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 700 : 1 (Typ.) (TM) |
| ikuspegi angelua | 75/75/70/75 (Typ.)(CR≥10) |
| erantzuna | 20/20 (Typ.)(Tr/Td) ms |
| ikuspegi ona | - |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 16.7M |
| atzeko argia | 5S3P WLED , 30K hours , With LED Driver |
| masa | TBD |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | 4-wire Resistive Touch |
| seinale mota | LVDS (1 ch, 8-bit) , Connector 20 pins |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
