| PartZenbakia | AM-1024600K5TMQW-04H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1024×600 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 700:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 8S3P |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| pantailaren tamaina | 7.0 inch |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 169PPI |
| eremu aktiboa (mm) | 153.6 × 90 (H×V) |
| bezela eremua (mm) | 156.2 × 92.6 (H×V) |
| luminantzia | 1000 cd/m² (Typ.) |
| ikuspegi angelua | 75/75/70/75 (Typ.)(CR≥10) |
| ikuspegi ona | - |
| kolore-sakonera | 262K/16.7M |
| masa | TBD |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| tentsio-hornidura | 3.3/11/16/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | AM-1024600K5TMQW-04H |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 165.5 × 104.44 × 5.3 (H×V×D) |
| tratamendua | Glare (Haze 0%), Hard coating |
| kontraste-erlazioa | 700 : 1 (Typ.) (TM) |
| erantzuna | 20/20 (Typ.)(Tr/Td) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | 8S3P WLED , 50K hours , No Driver |
| erabiltzen | Industrial Outdoor High Brightness |
| pantaila taktila | Without |
