| PartZenbakia | HE070IA-04M |
| Marka | Innolux |
| Tamaina | 7.0 |
| Aplikazio | PAD |
| Ebazpena | 800×1280 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | No B/L |
| Interfazea | MIPI |
| panel marka | INNOLUX |
| panel eredua | HE070IA-04M |
| panel mota | a-Si TFT-LCD , CELL |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×1280 , WXGA |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 94.2×150.72 mm |
| eskema | 101.5×159.52×0.77 mm |
| azalera | Hard coating |
| beiraren sakonera | 0.25+0.25 mm |
| transmisibitatea | 3.6% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193160% |
| erantzun denbora | 15/25 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | MIPI (4 data lanes), 40 pins |
| sarrerako tentsioa | 3.3/8.8/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikazio | PAD |
