| PartZenbakia | LTP500GV-F01 |
| Marka | Samsung |
| Tamaina | 5.0 |
| Aplikazio | PDA |
| Ebazpena | 480×640 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 250:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SAMSUNG |
| panel eredua | LTP500GV-F01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 480(RGB)×640 , VGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 75.6×100.8 mm |
| eskema | 83.84×113.2×4.8 mm |
| azalera | |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 250:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193140% |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | 40/30/50/50 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S4PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 60 pins |
| sarrerako tentsioa | 3.3/8.0/16.0/-8.4V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | PDA |
| ACX534AKM-2 | SONY | 5.0 | 800×600 |
| AT050TN34 V.1 | Innolux | 5.0 | 480×272 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LQ050T1SX02 | SHARP | 5.0 | 1080×1920 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| PA050XSG | E Ink | 5.0 | 320×234 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
