| PartZenbakia | WG12232E-YYH-N#A |
| Marka | Winstar |
| Tamaina | 2.2 |
| Aplikazio | Industrial Instrumen |
| Ebazpena | 122×32 |
| Konposizioa | STN-LCD , LCM |
| Distira | |
| CR | 3:1 |
| Koloreak | Monochrome |
| Atzeko argia | YG-LED |
| Interfazea | 8-bit |
| marka | Winstar |
| diagonalaren tamaina | 2.2 inch |
| pixel formatua | 122×32 57PPI |
| eremu aktiboa | 53.64(H)×15.64(V) mm |
| bezela eremua | 60.0(H)×18.0(V) mm |
| luminantzia | - |
| ikusi norabidea | 6 o'clock |
| ikuspegi angelua | 30/30/20/40 (Typ.)(CR≥2) |
| euskarria kolorea | Monochrome |
| pisua | - |
| fotograma-tasa | - |
| interfaze mota | 8-bit 6800/8080 parallel , 20 pins Pad |
| energia hornidura | 5.0V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| eredua | WG12232E-YYH-N#A |
| mota | STN-LCD , LCM |
| konfigurazioa | Rectangle |
| eskema dim. | 80(H)×36(V) ×10.2(D) mm |
| tratamendua | - |
| kontraste-erlazioa | 3:1 (Typ.) (TM) |
| erantzun denbora | 100/100 (Typ.)(Tr/Td) |
| funtzionamendu modua | STN, Yellow/Green (Positive), Transflective |
| argi iturria | YG-LED , 100K hours , W/O Driver |
| entzat diseinatua | Industrial Instruments & Meters |
| ukipen-panela | Without |
