| PartZenbakia | WEO012832AG |
| Marka | Winstar |
| Tamaina | 2.2 |
| Aplikazio | Handheld & PDA Instr |
| Ebazpena | 128×32 |
| Konposizioa | PM-OLED , OLED |
| Distira | |
| CR | |
| Koloreak | Mono(Green) |
| Atzeko argia | self |
| Interfazea | 8-bit |
| marka | Winstar |
| diagonalaren tamaina | 2.2 inch |
| pixel formatua | 128×32 59PPI |
| eremu aktiboa | 55.018(H)×13.098(V) mm |
| bezela eremua | 57.02(H)×15.1(V) mm |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | - |
| euskarria kolorea | Mono(Green) |
| pisua | - |
| fotograma-tasa | - |
| d-ic xehetasuna | COG Built-in SSD1305Z |
| interfaze mota | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| energia hornidura | 3.0V (Typ.) |
| eredua | WEO012832AG |
| mota | PM-OLED , OLED |
| konfigurazioa | Rectangle |
| eskema dim. | 62(H)×24(V) ×2.35(D) mm |
| tratamendua | - |
| erantzun denbora | - |
| funtzionamendu modua | - |
| argi iturria | self |
| entzat diseinatua | Handheld & PDA Instruments & Meters |
| ukipen-panela | Without |
