| PartZenbakia | TX09D70VM1CEA |
| Marka | KOE |
| Tamaina | 3.5 |
| Aplikazio | HHP |
| Ebazpena | 240×320 |
| Konposizioa | LCM |
| Distira | 320 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | HITACHI |
| panel eredua | TX09D70VM1CEA |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 240(RGB)×320 , QVGA |
| bistaratzeko modua | TN, Normally White, TMR |
| eremu aktiboa | 53.64×71.52 mm |
| eskema | 64×86×5.5 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 320 cd/m² (Typ.) |
| kontraste-erlazioa | 300 : 1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/80/60 (Typ.)(CR≥5)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S2PWLEDWithout Driver |
| seinale interfazea | CMOS (1 ch, 6-bit), 50 pins |
| sarrerako tentsioa | 3.3/8.48/15.0/-5.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikazio | HHP |
