| PartZenbakia | A035VL01 V3 |
| Marka | AUO |
| Tamaina | 3.5 |
| Aplikazio | DVC |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 315 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | AUO |
| panel eredua | A035VL01 V3 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 75.6×45.36 mm |
| eskema | 86.1×51.66 mm |
| azalera | Glare (Haze 0%) |
| distira | 315 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 15/30 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| sarrerako tentsioa | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplikazio | DVC |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| A035VL01 V6 | AUO | 3.5 | 800×480 |
| CT035TN02 | Innolux | 3.5 | 320×480 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| NL2432HC22-25E | NLT | 3.5 | 240×320 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| UMSH-8065MD-11T | Other | 3.5 | 320×240 |
| 990000553 | TPO | 3.5 | 320×240 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| COM48T4Mxxxxx | ORTUSTECH | 4.8 | 1920×1080 |
| LS032V8DY01 | SHARP | 3.2 | 640×480 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
