| PartZenbakia | CLAA035JA01CW |
| Marka | CPT |
| Tamaina | 3.5 |
| Aplikazio | |
| Ebazpena | 144×480 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | CPT |
| panel eredua | CLAA035JA01CW |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 144(RGB)×480 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 25.92×86.4 mm |
| eskema | 33.9×100.2 mm |
| azalera | Antiglare |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 2S2PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| sarrerako tentsioa | 2.8/2.8/2.8V (Typ.)(VCC/VCI/IOVCC) |
| rohs: |
