| PartZenbakia | YX035CM31 |
| Marka | |
| Tamaina | 3.5 |
| Aplikazio | HHP |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 800 |
| CR | 400:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | Parallel/Serial |
| panel marka | |
| panel eredua | YX035CM31 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 70.08×52.56 mm |
| eskema | 76.9×63.9 mm |
| azalera | Antiglare (Haze 20%) |
| distira | 800 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 10/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S2PWLEDWithout Driver |
| seinale interfazea | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| sarrerako tentsioa | 3.3/13.9/13.6V (Typ.)(VCC/VGH/VGL) |
| aplikazio | HHP |
