| PartZenbakia | TM070JDHP01-00 |
| Marka | Tianma |
| Tamaina | 7.0 |
| Aplikazio | UMPC |
| Ebazpena | 1280×800 |
| Konposizioa | LCM |
| Distira | 420 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | TIANMA |
| panel eredua | TM070JDHP01-00 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 1280(RGB)×800 , WXGA |
| bistaratzeko modua | SIP, Normally Black, Transmissive |
| eremu aktiboa | 149.76×93.6 mm |
| eskema | 161×107×4.4 mm |
| azalera | Antireflection |
| distira | 420 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 9S2PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 8-bit), 39 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | UMPC |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| AT070TN90 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.3 | Innolux | 7.0 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| FG0700G3DSSWBGL4 | Data Image | 7.0 | 800×480 |
| HJ070NA-01U | Innolux | 7.0 | 1024×600 |
| HV070WS1-1E1 | HYDIS | 7.0 | 1024×600 |
| LMS700KF05 | Samsung | 7.0 | 800×480 |
| LTN070NL01-801 | Samsung | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| HV056WX2-100 | HYDIS | 5.6 | 1280×800 |
| LB048WV1-TL01 | LG Display | 4.8 | 800×480 |
| LD070WS2-SL03 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL06 | LG Display | 7.0 | 1024×600 |
| LT080EE04100 | TOSHIBA | 8.0 | 1600×768 |
| LTD056ET0T | TOSHIBA | 5.6 | 1024×600 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
