| PartZenbakia | TL055BDXP03 |
| Marka | TIANMA |
| Tamaina | 5.5 |
| Aplikazio | Mobile Phone |
| Ebazpena | 1440×2560 |
| Konposizioa | LCM , LTPS TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 5S3P |
| Interfazea | MIPI |
| fabrikatzailea | TIANMA |
| pantailaren tamaina | 5.5 inch |
| pixel-zenbakia | 1440(RGB)×2560 (Quad-HD) 537PPI |
| eremu aktiboa (mm) | 68.04 × 120.96 (H×V) |
| luminantzia | - |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 70% NTSC |
| masa | TBD |
| freskatze tasa | 70Hz |
| seinale mota | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| tentsio-hornidura | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| ereduaren izena | TL055BDXP03 |
| pantaila mota | LCM , LTPS TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| erantzuna | 8 (Typ.)(Tr+Td) ms |
| lan egiteko modua | SFT, Normally Black, Transmissive |
| atzeko argia | 5S3P WLED |
| erabiltzen | Mobile Phone |
| pantaila taktila | Without |
