| PartZenbakia | LQ055W1GC01 |
| Marka | SHARP |
| Tamaina | 5.5 |
| Aplikazio | UMPC |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Mini LVDS |
| panel marka | SHARP |
| panel eredua | LQ055W1GC01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.5 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 119.808×70.2 mm |
| eskema | 130.2×81.15 mm |
| azalera | Clear, Hard coating (2H) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 60/50/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 8S1PWLEDWithout Driver |
| seinale interfazea | Mini LVDS, 40 pins |
| sarrerako tentsioa | 2.5/7.9V (Typ.)(VCC/VDD) |
| aplikazio | UMPC |
