| PartZenbakia | TD025THED2 |
| Marka | TPO |
| Tamaina | 2.5 |
| Aplikazio | MPH |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 350:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | TPO |
| panel eredua | TD025THED2 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 2.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 49.92×37.44 mm |
| eskema | 56.4×49.12×2.5 mm |
| azalera | |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 350:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193170% |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| ikuspegi angelua | 55/55/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| sarrerako tentsioa | 1.8/2.8V (Typ.)(VDDI/VDD) |
| aplikazio | MPH |
