| PartZenbakia | TCG057QVLAC-G00 |
| Marka | Kyocera |
| Tamaina | 5.7 |
| Aplikazio | IA |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 350 |
| CR | 450:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | Kyocera |
| panel eredua | TCG057QVLAC-G00 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.7 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 115.2×86.4 mm |
| eskema | 144×104.8×13.5 mm |
| azalera | Glare (Haze 0%) |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 450:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 10/25 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥5)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3 stringsWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 33 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| EL320.256-FD6 | Lumineq | 4.8 | 320×256 |
| KCB6448BSTT-X4 | Kyocera | 10.4 | 640×480 |
| KCS057QV1AJ-G39 | Kyocera | 5.7 | 320×240 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| OEL9M0065-Y-E | Other | 2.7 | 256×64 |
| SP14N002 | KOE | 5.1 | 240×128 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
| TM12864G3CCWGWA-1 | Tianma | 2.4 | 128×64 |
| UG-2864KLBLG01 | WiseChip | 1.3 | 128×64 |
