| PartZenbakia | P101DEA-AZ0 |
| Marka | Innolux |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 800×1280 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4 |
| Interfazea | MIPI |
| fabrikatzailea | Innolux |
| ereduaren izena | P101DEA-AZ0 |
| pantailaren tamaina | 10.1 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×1280 (WXGA) 150PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 135.36 × 216.576 (H×V) |
| eskema (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Glare (Haze 0%), Hard coating |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10) |
| erantzuna | 35 (Max.)(Tr+Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | AAS, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 60% NTSC |
| atzeko argia | 4 strings WLED , 15K hours , No Driver |
| masa | 175g (Max.) |
| erabiltzen | Pad & Tablet |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | MIPI (4 data lanes) , Connector 40 pins |
| tentsio-hornidura | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
