| PartZenbakia | NL6448BC20-08E |
| Marka | NLT |
| Tamaina | 6.5 |
| Aplikazio | IA |
| Ebazpena | 640×480 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 250:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | NEC |
| panel eredua | NL6448BC20-08E |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 6.5 inch |
| ebazpena | 640(RGB)×480 , VGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 132.48×99.36 mm |
| eskema | 178.8×126.8 mm |
| azalera | Antiglare (Haze 16%), Hard coating (2H), Antireflection |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 250:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193142% |
| erantzun denbora | 13/36 (Typ.)(Tr/Td) |
| ikuspegi angelua | 50/50/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | Parallel RGB, 31 pins |
| sarrerako tentsioa | 3.3/5.0V (Typ.)(VCC) |
| rohs: | |
| aplikazio | IA |
