| PartZenbakia | NL10276AC24-05 |
| Marka | NLT |
| Tamaina | 12.1 |
| Aplikazio | DMPC |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 150:1 |
| Koloreak | Full color |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | NEC |
| panel eredua | NL10276AC24-05 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 12.1 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 245.76×184.32 mm |
| eskema | 290×225×17 mm |
| azalera | |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 150:1 (Typ.) |
| bistaratzeko koloreak | Full color , CIE193140% |
| erantzun denbora | 40 (Max.)(Tr) |
| ikuspegi angelua | 50/50/20/20 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 2 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | Analog RGB, 31 pins |
| sarrerako tentsioa | 3.3/12V (Typ.)(VCC/VDD) |
| aplikazio | DMPC |
