| PartZenbakia | M090AWP4 R1 |
| Marka | IVO |
| Tamaina | 9.0 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 700:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| fabrikatzailea | IVO |
| pantailaren tamaina | 9.0 inch |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 104PPI |
| eremu aktiboa (mm) | 198 × 112.08 (H×V) |
| bezela eremua (mm) | 200.2 × 114.28 (H×V) |
| luminantzia | 750 cd/m² (Typ.) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10) |
| ikuspegi ona | 6 o'clock |
| kolore-sakonera | 262K 70% NTSC |
| masa | - |
| freskatze tasa | 60Hz |
| seinale mota | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| gehienez. balorazioak | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| ereduaren izena | M090AWP4 R1 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| tratamendua | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 700 : 1 (Typ.) (TM) |
| erantzuna | 12 (Typ.)(Tr+Td) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | WLED , No Driver |
| erabiltzen | Outdoor High Brightness Automotive Display |
| pantaila taktila | Without |
