| PartZenbakia | LTM238HP01 |
| Marka | SAMSUNG |
| Tamaina | 23.8 |
| Aplikazio | Desktop Monitor |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 3000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | SAMSUNG |
| ereduaren izena | LTM238HP01 |
| pantailaren tamaina | 23.8 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 1920(RGB)×1080 (FHD) 92PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 527.04 × 296.46 (H×V) |
| eskema (mm) | - |
| luminantzia | - |
| kontraste-erlazioa | 3000 : 1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| erantzuna | 14 (Typ.)(G to G) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | PVA, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 72% NTSC |
| atzeko argia | WLED |
| masa | - |
| erabiltzen | Desktop Monitor |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (2 ch, 8-bit) , 30 pins Connector |
| tentsio-hornidura | 5.0V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
