| PartZenbakia | LTM236FL01 |
| Marka | Samsung |
| Tamaina | 23.6 |
| Aplikazio | DMPC |
| Ebazpena | 3840×2160 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | eDP |
| panel marka | SAMSUNG |
| panel eredua | LTM236FL01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 23.6 inch |
| ebazpena | 3840(RGB)×2160 , UHD |
| bistaratzeko modua | PLS, Normally Black, Transmissive |
| eremu aktiboa | 521.28×293.22 mm |
| eskema | 544.8×320.5×11 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), sRGB100% |
| erantzun denbora | 14 (Typ.)(G to G) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 stringsWLEDWithout Driver |
| seinale interfazea | eDP (4 Lanes), 51 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
