| PartZenbakia | CLAA170EA07 |
| Marka | CPT |
| Tamaina | 17.0 |
| Aplikazio | DMPC |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 500:1 |
| Koloreak | 16.2M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | CPT |
| panel eredua | CLAA170EA07 2 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1280(RGB)×1024 , SXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 337.92×270.336 mm |
| eskema | 358.5×296.5×17.5 mm |
| azalera | Antiglare |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 16.2M (6-bit + FRC), CIE193172% |
| erantzun denbora | 5/7 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/67/63 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101ND07CW | CPT | 10.1 | 1024×600 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| CLAA102NC01CW | CPT | 10.2 | 1024×600 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| CLAA184FP01 | CPT | 18.4 | 1920×1080 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| LTM150XH-L01 | Samsung | 15.0 | 1024×768 |
| LTM220M3-L02 | Samsung | 22.0 | 1680×1050 |
| M185B3-LA1 | Innolux | 18.5 | 1366×768 |
| M185BGE-L23 | Innolux | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
| M215HTN01.1 | AUO | 21.5 | 1920×1080 |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| MT220WW01 V.6 | Innolux | 22.0 | 1680×1050 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
