| PartZenbakia | LTL089CL02-001 |
| Marka | Samsung |
| Tamaina | 8.9 |
| Aplikazio | PAD |
| Ebazpena | 1920×1200 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 900:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | SAMSUNG |
| panel eredua | LTL089CL02-001 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.9 inch |
| ebazpena | 1920(RGB)×1200 , WUXGA |
| bistaratzeko modua | PLS, Normally Black, Transmissive |
| eremu aktiboa | 191.52×119.7 mm |
| eskema | 203.5×135.9×5.2 mm |
| azalera | Glare (Haze 0%), Hard coating (2H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 900:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S5PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 45 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
