| PartZenbakia | B116XAN01.0 |
| Marka | AUO |
| Tamaina | 11.6 |
| Aplikazio | PAD |
| Ebazpena | 1366×768 |
| Konposizioa | LCM |
| Distira | 700 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | AUO |
| panel eredua | B116XAN01.0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 11.6 inch |
| ebazpena | 1366(RGB)×768 , WXGA |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| eremu aktiboa | 256.125×144 mm |
| eskema | 267.17×157.31×4.74 mm |
| azalera | |
| distira | 700 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Min.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 30 (Max.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 8S6PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 45 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
