| PartZenbakia | LQ070T5BG01 |
| Marka | SHARP |
| Tamaina | 7.0 |
| Aplikazio | VDP |
| Ebazpena | 480×234 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 60:1 |
| Koloreak | Full color |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | SHARP |
| panel eredua | LQ070T5BG01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 480(RGB)×234 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 155.52×87.75 mm |
| eskema | 173×106 mm |
| azalera | Antiglare |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 60:1 (Min.) |
| bistaratzeko koloreak | Full color |
| erantzun denbora | 30/50 (Typ.)(Tr/Td) |
| ikuspegi angelua | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| sarrerako tentsioa | 5.3/13/-16V (VSH/VGH/VGL) |
| aplikazio | VDP |
