| PartZenbakia | LH500WF1-SD02 |
| Marka | LG Display |
| Tamaina | 5.0 |
| Aplikazio | MPH |
| Ebazpena | 1080×1920 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | LG Display |
| panel eredua | LH500WF1-SD02 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 1080(RGB)×1920 , FHD |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| eremu aktiboa | 62.37×110.88 mm |
| eskema | 65.27×117.88×1.55 mm |
| azalera | Clear |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 20/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S2PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 30 pins |
| sarrerako tentsioa | 1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN) |
| aplikazio | MPH |
