| PartZenbakia | LS038Y7DX01 |
| Marka | SHARP |
| Tamaina | 3.8 |
| Aplikazio | MPH |
| Ebazpena | 480×800 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LS038Y7DX01 |
| panel mota | CG-Silicon , LCM |
| panelaren tamaina | 3.8 inch |
| ebazpena | 480(RGB)×800 , WVGA |
| bistaratzeko modua | Normally Black, Transflective |
| eremu aktiboa | 49.68×82.8 mm |
| eskema | 54.6×93 mm |
| azalera | |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit), CIE193170% |
| erantzun denbora | 40/40 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| sarrerako tentsioa | 3.85/1.8V (Typ.)(VDC/VDDIO) |
| rohs: | |
| aplikazio | MPH |
