| PartZenbakia | LS050T1SX12(K) |
| Marka | SHARP |
| Tamaina | 5.0 |
| Aplikazio | MPH |
| Ebazpena | 1080×1920 |
| Konposizioa | LCM |
| Distira | 460 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | SHARP |
| panel eredua | LS050T1SX12(K) |
| panel mota | CG-Silicon , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 1080(RGB)×1920 , FHD |
| bistaratzeko modua | New Mode2, Normally Black, Transmissive |
| eremu aktiboa | 61.641×109.584 mm |
| eskema | 64.041×116.224×1.13 mm |
| azalera | Hard coating (3H) |
| distira | 460 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193195% |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S2PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 34 pins |
| sarrerako tentsioa | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| aplikazio | MPH |
