| PartZenbakia | LA090WH1-SL01 |
| Marka | LG Display |
| Tamaina | 9.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1280×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | LG Display |
| eredua | LA090WH1-SL01 |
| diagonalaren tamaina | 9.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1280(RGB)×720 [WXGA] 164PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 200.448(H)×106.056(V) mm |
| eskema dim. | 213.2(H)×121.2(V) ×8.6(D) mm |
| bezela eremua | 203.148(H)×108.756(V) mm |
| tratamendua | Antiglare |
| luminantzia | 600 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 17/13 (Max.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10) |
| funtzionamendu modua | IPS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 65% NTSC |
| argi iturria | WLED [6S3P] , 10K hours , W/O Driver |
| pisua | 219/224g (Typ./Max.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 8-bit) , 60 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
