| PartZenbakia | A090VW01 V3 |
| Marka | AUO |
| Tamaina | 9.0 |
| Aplikazio | DPF |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 500:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | AUO |
| panel eredua | A090VW01 V3 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.0 inch |
| ebazpena | 800×480(RGB) , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 199.2×110.16 mm |
| eskema | 211.7×125 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193148% |
| erantzun denbora | 4/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 3S8PWLEDWithout Driver |
| seinale interfazea | TTL (1 ch, 8-bit) + SPI, 68 pins |
| sarrerako tentsioa | 3.3/5.5/-5.5/10/-13V (Typ.)(VCC/VDPA/VDNA/VGH/VGL) |
| aplikazio | DPF |
