| PartZenbakia | HX121WX1-100 |
| Marka | HYDIS |
| Tamaina | 12.1 |
| Aplikazio | PAD |
| Ebazpena | 1280×800 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 700:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE HYDIS |
| panel eredua | HX121WX1-100 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 12.1 inch |
| ebazpena | 1280(RGB)×800 , WXGA |
| bistaratzeko modua | AFFS, Normally Black, Transflective |
| eremu aktiboa | 261.12×163.2 mm |
| eskema | 276.8×180×6.8 mm |
| azalera | Hard coating (2H), Antireflection |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.)(Transmissive) |
| bistaratzeko koloreak | 262K (6-bit), CIE193142% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 90/90/90/90 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 12S4PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-103 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-110 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| M121MNS1 R1 | IVO | 12.1 | 800×600 |
| N121I7-L01 | Innolux | 12.1 | 1280×800 |
| NL8060BC31-02 | NLT | 12.1 | 800×600 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
| AMS767KC04-1 | Samsung | 7.7 | 1280×800 |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| HV121WX5-114 | HYDIS | 12.1 | 1280×800 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TV096WXM-NS0 | BOE | 9.6 | 800×1280 |
