| PartZenbakia | HX104X02-100 |
| Marka | HYDIS |
| Tamaina | 10.4 |
| Aplikazio | PAD |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 340 |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HYDIS |
| panel eredua | HX104X02-100 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.4 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | AFFS+, Normally Black, Transmissive |
| eremu aktiboa | 210.4×157.8 mm |
| eskema | 238.6×173.2×6.8 mm |
| azalera | Antiglare, Antireflection |
| distira | 340 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193140% |
| erantzun denbora | 36 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 7S6PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
